2009 TRIO CT3042

Description

SKU: 123706

Model: CT3042

Year: 2009

Condition: Used

S/N: AC288

Made In: CHINA

Additional Description:

The CT series uses high strength, low carbon alloy steel cast front and rear frames, with doweled and bolted side frames to ensure the rigidity of the machine.

The bolted main frame significantly increases the machine's loading capability. The non-welded design eliminates residual strains providing longer service life.

The modular design provides extra value by reducing transportation and installation cost for underground mining applications.

Feed opening size: 30" x 42"

Max. Capacity: 150-550 MTPH

Closed side setting: 3" - 8"

Open circuit max. capabilities:

- 3": 150-200 tph

- 3 1/2": 180-230 tph

- 4": 200-260 tph

- 5": 230-460 tph

- 6": 300-400 tph

- 7": 350-460 tph

Horsepower: 250 hp

Max. Speed: 250 rpm

Power: 110 kW

Weight: 54,905 lbs

Features of CT series:

- Operates in the most demanding environments

- Ideal for open pit and underground primary applications

- Rugged, Robust, and Reliable

- Capable of high reduction ratios in high production applications

- Easy transport and installation

- Hydraulic CSS adjustment

- Easy to operate and maintain
