2014 REV GCV8.5

Description

The GCV 8.5 Impact Crusher has the features normally only associated with larger Impact Crushers, including an optional return circuit screen enabling the product to recycle until reaching the desired size. This alone makes the GCV 8.5/S unique in the market for a machine of only 28.5 tonne. Featuring a robust design and a six meter feed hopper, the GCV 8.5/S can make those small uneconomical crushing projects profitable with reduced mobilization and a single processing plant, or operating in conjunction with a jaw crusher as a secondary crusher and screen. The GCV 8.5 and 8.5/S would have to be one of the most economical and flexible machines in the market with an affordable price tag.

Big Crusher Features

Hydraulic Adjustment

Return Screen Option

Single Processing Machine

SPECIFICATIONS

Vibrating Grizzly Feeder

Crusher Opening: 800x550 mm

Crusher Adjustment (Hydraulic): 30-90 mm

Max feed size: 350 mm

Production: 50-200 tonne P/H

Hopper size: 6 m

Engine: Cat C7 Acert 187 kw

Main Conveyor Belt: 1000mm x 9.7 m

GCV 8.5/S - attached screen & return conveyor

Screen Box: 3000x1250mm

Fines Conveyor belt from screen: 1000mm x 5.7 m

Oversize side conveyor: 400mm x 2.3 m

Recycling conveyor belt: 400mm x 8 m

TRANSPORT DIMENSIONS

Width: 2,550 mm

Length: 10,400 mm

Height: 3,130 mm

Weight: 28,500 tonne

OPTIONS

Fines Belt

Magnetic - Over Band

Dust Control

Foldable Main Conveyor
