2022 TEREX FINLAY C1540P

Description

FINLAY C-1540P TRACKED CONE CRUSHER EQUIPPED AS PER BELOW:

ENGINE:

- TIER 4 FINAL/STAGE IV: SCANIA DC09 257KW (350 HP)

CONE CHAMBER:

- TEREX TC1000 CONE CRUSHER

- LONG THROW ECCENTRIC, MEDIUM COARSE CONCAVE (MAX FEED SIZE 160MM)

- HYDROSTATIC CONE DRIVE

FEED/CONVEYOR HOPPER:

- FIXED WEAR RESISTANT HOPPER

- 1050MM (42") WIDE BELT

- METAL DETECTOR & METAL CONTAMINANTS PURGE SYSTEM

- MANUAL HOPPER EXTENSIONS

MAIN CONVEYOR:

- 900MM (36") WIDE BELT

- DUST COVERS

PRE-SCREEN:

- 1.83M X 1.22M (6' X 4') SINGLE DECK SCREEN.

- 16MM APERTURE MESH FITTED

- MAX FEED SIZE 160MM

- REQUIRES 1 AUXILIARY DRIVE

- SIDE CONVEYOR

CLIMATE SPEC:

- STANDARD OILS (RECOMMENDED FOR AMBIENT TEMPERATURES BETWEEN -5 TO +30 DEGREES

CELSIUS)

DUST SUPPRESSION:

- PIPED FOR DUST SUPPRESSION C/W SPRAYBARS

ELECTRICAL:

- EMERGENCY STOPS

- HAND HELD TRACK CONTROL SET WITH CONNECTION LEAD

- RADIO REMOTE SYSTEM

- CONTROL PANEL POSITIVE AIR PRESSURIZATION

GENERAL:

- SAFETY GUARDS IN COMPLIANCE OF MACHINERY DIRECTIVE, END USER TO HAVE GUARDING

INSPECTED

- TWO AUXILIARY DRIVES - (NOTE-SOME OPTIONS REQUIRE AN AUXILARY WHICH USE THESE)
