2024 ARK J-2716

Description

12" - 18" Size In

3/4" - 3 1/4" Size Out

90 tph

Doosan Tier 4 Final 74hp

27" x 16" Jaw Size

28'7" ✕ 7'3" ✕ 8'1" Working Size

18'1" ✕ 7'3" ✕ 7'3" Transport Size

26,450 lbs. Weight

The ARK J-2716 is designed for operators that need a versatile and mobile machine. It is small enough to fit inside a container for transport but strong enough to withstand the toughest of applications. This crusher features a pair of 27" ✕ 16" single toggle jaws that can be adjusted hydraulically down to 3/4". There is also a feed sensor, or "magic eye" above the jaws which is used to start and stop the vibrating feeder to prevent blockages and keep the machine running at maximum efficiency.
